Dip SL_NextGen Components, Inc.

Dip SL

ALL

Description and Main Parameters	Part Code	Dimension	Original Part Number	Documents
Capacitance: 820µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 3860mA Max. Load Life: 10000 Hours,0.026Ω	SL827M100HLORR CBE827M2AHSLL40RR	Ø18.0xL40.0mm	CBE827M2AHSLL40RR	Data Sheet	View Inventory
Capacitance: 680µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 3510mA Max. Load Life: 10000 Hours,0.027Ω	SL687M100HLNRR CBE687M2AHSLL3ERR	Ø18.0xL35.5mm	CBE687M2AHSLL3ERR	Data Sheet	View Inventory
Capacitance: 680µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 3510mA Max. Load Life: 10000 Hours,0.027Ω	SL687M100HKORR CBE687M2AHSLK40RR	Ø16.0xL40.0mm	CBE687M2AHSLK40RR	Data Sheet	View Inventory
Capacitance: 560µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 2860mA Max. Load Life: 10000 Hours,0.030Ω	SL567M100HLLRR CBE567M2AHSLL3ARR	Ø18.0xL31.5mm	CBE567M2AHSLL3ARR	Data Sheet	View Inventory
Capacitance: 560µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 2860mA Max. Load Life: 10000 Hours,0.029Ω	SL567M100HKNRR CBE567M2AHSLK3ERR	Ø16.0xL35.5mm	CBE567M2AHSLK3ERR	Data Sheet	View Inventory
Capacitance: 470µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 2500mA Max. Load Life: 10000 Hours,0.036Ω	SL477M100HLJRR CBE477M2AHSLL25RR	Ø18.0xL25.0mm	CBE477M2AHSLL25RR	Data Sheet	View Inventory
Capacitance: 470µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 2640mA Max. Load Life: 10000 Hours,0.032Ω	SL477M100HKLRR CBE477M2AHSLK3ARR	Ø16.0xL31.5mm	CBE477M2AHSLK3ARR	Data Sheet	View Inventory
Capacitance: 390µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 2270mA Max. Load Life: 10000 Hours,0.045Ω	SL397M100HLHRR CBE397M2AHSLL20RR	Ø18.0xL20.0mm	CBE397M2AHSLL20RR	Data Sheet	View Inventory
Capacitance: 390µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 2430mA Max. Load Life: 10000 Hours,0.038Ω	SL397M100HKJRR CBE397M2AHSLK25RR	Ø16.0xL25.0mm	CBE397M2AHSLK25RR	Data Sheet	View Inventory
Capacitance: 270µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 1950mA Max. Load Life: 10000 Hours,0.048Ω	SL277M100HKHRR CBE277M2AHSLK20RR	Ø16.0xL20.0mm	CBE277M2AHSLK20RR	Data Sheet	View Inventory
Capacitance: 270µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 2400mA Max. Load Life: 10000 Hours,0.042Ω	SL277M100HJKRR CBE277M2AHSLJ30RR	Ø13.0xL30.0mm	CBE277M2AHSLJ30RR	Data Sheet	View Inventory
Capacitance: 220µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 2210mA Max. Load Life: 10000 Hours,0.047Ω	SL227M100HJJRR CBE227M2AHSLJ25RR	Ø13.0xL25.0mm	CBE227M2AHSLJ25RR	Data Sheet	View Inventory
Capacitance: 150µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 1750mA Max. Load Life: 10000 Hours,0.062Ω	SL157M100HJHRR CBE157M2AHSLJ20RR	Ø13.0xL20.0mm	CBE157M2AHSLJ20RR	Data Sheet	View Inventory
Capacitance: 120µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 1620mA Max. Load Life: 10000 Hours,0.069Ω	SL127M100HGJRR CBE127M2AHSLG25RR	Ø10.0xL25.0mm	CBE127M2AHSLG25RR	Data Sheet	View Inventory
Capacitance: 100µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 1430mA Max. Load Life: 10000 Hours,0.084Ω	SL107M100HGHRR CBE107M2AHSLG20RR	Ø10.0xL20.0mm	CBE107M2AHSLG20RR	Data Sheet	View Inventory
Capacitance: 82µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 1040mA Max. Load Life: 10000 Hours,0.11Ω	SL826M100HGGRR CBE826M2AHSLG16RR	Ø10.0xL16.0mm	CBE826M2AHSLG16RR	Data Sheet	View Inventory
Capacitance: 68µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 1040mA Max. Load Life: 9000 Hours,0.16Ω	SL686M100HFHRR CBE686M2AHSLF20RR	Ø8.00xL20.0mm	CBE686M2AHSLF20RR	Data Sheet	View Inventory
Capacitance: 56µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 780mA Max. Load Life: 9000 Hours,0.17Ω	SL566M100HGDRR CBE566M2AHSLG1BRR	Ø10.0xL12.5mm	CBE566M2AHSLG1BRR	Data Sheet	View Inventory
Capacitance: 47µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 780mA Max. Load Life: 9000 Hours,0.20Ω	SL476M100HFGRR CBE476M2AHSLF16RR	Ø8.00xL16.0mm	CBE476M2AHSLF16RR	Data Sheet	View Inventory
Capacitance: 33µF, Tol. ±20%, Voltage 100V, Bulk Ripple Current 620mA Max. Load Life: 8000 Hours,0.29Ω	SL336M100HFCRR CBE336M2AHSLF12RR	Ø8.00xL12.0mm	CBE336M2AHSLF12RR	Data Sheet	View Inventory
Capacitance: 820µF, Tol. ±20%, Voltage 63V, Bulk Ripple Current 2890mA Max. Load Life: 10000 Hours,0.025Ω	SL827M063HKJRR CBE827M1JHSLK25RR	Ø16.0xL25.0mm	CBE827M1JHSLK25RR	Data Sheet	View Inventory
Capacitance: 680µF, Tol. ±20%, Voltage 63V, Bulk Ripple Current 2800mA Max. Load Life: 10000 Hours,0.026Ω	SL687M063HJKRR CBE687M1JHSLJ30RR	Ø13.0xL30.0mm	CBE687M1JHSLJ30RR	Data Sheet	View Inventory
Capacitance: 560µF, Tol. ±20%, Voltage 63V, Bulk Ripple Current 2380mA Max. Load Life: 10000 Hours,0.032Ω	SL567M063HKHRR CBE567M1JHSLK20RR	Ø16.0xL20.0mm	CBE567M1JHSLK20RR	Data Sheet	View Inventory
Capacitance: 560µF, Tol. ±20%, Voltage 63V, Bulk Ripple Current 2760mA Max. Load Life: 10000 Hours,0.028Ω	SL567M063HJKRR CBE567M1JHSLJ30RR	Ø13.0xL30.0mm	CBE567M1JHSLJ30RR	Data Sheet	View Inventory
Capacitance: 470µF, Tol. ±20%, Voltage 63V, Bulk Ripple Current 2460mA Max. Load Life: 10000 Hours,0.031Ω	SL477M063HJJRR CBE477M1JHSLJ25RR	Ø13.0xL25.0mm	CBE477M1JHSLJ25RR	Data Sheet	View Inventory
Capacitance: 390µF, Tol. ±20%, Voltage 63V, Bulk Ripple Current 1990mA Max. Load Life: 10000 Hours,0.041Ω	SL397M063HJHRR CBE397M1JHSLJ20RR	Ø13.0xL20.0mm	CBE397M1JHSLJ20RR	Data Sheet	View Inventory
Capacitance: 330µF, Tol. ±20%, Voltage 63V, Bulk Ripple Current 1990mA Max. Load Life: 10000 Hours,0.046Ω	SL337M063HGJRR CBE337M1JHSLG25RR	Ø10.0xL25.0mm	CBE337M1JHSLG25RR	Data Sheet	View Inventory
Capacitance: 270µF, Tol. ±20%, Voltage 63V, Bulk Ripple Current 1570mA Max. Load Life: 10000 Hours,0.056Ω	SL277M063HGHRR CBE277M1JHSLG20RR	Ø10.0xL20.0mm	CBE277M1JHSLG20RR	Data Sheet	View Inventory
Capacitance: 220µF, Tol. ±20%, Voltage 63V, Bulk Ripple Current 1200mA Max. Load Life: 10000 Hours,0.076Ω	SL227M063HGGRR CBE227M1JHSLG16RR	Ø10.0xL16.0mm	CBE227M1JHSLG16RR	Data Sheet	View Inventory
Capacitance: 180µF, Tol. ±20%, Voltage 63V, Bulk Ripple Current 1200mA Max. Load Life: 10000 Hours,0.076Ω	SL187M063HGGRR CBE187M1JHSLG16RR	Ø10.0xL16.0mm	CBE187M1JHSLG16RR	Data Sheet	View Inventory
Capacitance: 150µF, Tol. ±20%, Voltage 63V, Bulk Ripple Current 1200mA Max. Load Life: 9000 Hours,0.096Ω	SL157M063HFHRR CBE157M1JHSLF20RR	Ø8.00xL20.0mm	CBE157M1JHSLF20RR	Data Sheet	View Inventory
Capacitance: 120µF, Tol. ±20%, Voltage 63V, Bulk Ripple Current 990mA Max. Load Life: 9000 Hours,0.11Ω	SL127M063HGDRR CBE127M1JHSLG1BRR	Ø10.0xL12.5mm	CBE127M1JHSLG1BRR	Data Sheet	View Inventory
Capacitance: 100µF, Tol. ±20%, Voltage 63V, Bulk Ripple Current 990mA Max. Load Life: 9000 Hours,0.13Ω	SL107M063HFGRR CBE107M1JHSLF16RR	Ø8.00xL16.0mm	CBE107M1JHSLF16RR	Data Sheet	View Inventory
Capacitance: 82µF, Tol. ±20%, Voltage 63V, Bulk Ripple Current 720mA Max. Load Life: 8000 Hours,0.18Ω	SL826M063HFCRR CBE826M1JHSLF12RR	Ø8.00xL12.0mm	CBE826M1JHSLF12RR	Data Sheet	View Inventory
Capacitance: 1000µF, Tol. ±20%, Voltage 50V, Bulk Ripple Current 3510mA Max. Load Life: 10000 Hours,0.022Ω	SL108M050HKJRR CBE108M1HHSLK25RR	Ø16.0xL25.0mm	CBE108M1HHSLK25RR	Data Sheet	View Inventory
Capacitance: 820µF, Tol. ±20%, Voltage 50V, Bulk Ripple Current 3070mA Max. Load Life: 10000 Hours,0.026Ω	SL827M050HKHRR CBE827M1HHSLK20RR	Ø16.0xL20.0mm	CBE827M1HHSLK20RR	Data Sheet	View Inventory
Capacitance: 820µF, Tol. ±20%, Voltage 50V, Bulk Ripple Current 3370mA Max. Load Life: 10000 Hours,0.023Ω	SL827M050HJKRR CBE827M1HHSLJ30RR	Ø13.0xL30.0mm	CBE827M1HHSLJ30RR	Data Sheet	View Inventory
Capacitance: 680µF, Tol. ±20%, Voltage 50V, Bulk Ripple Current 2800mA Max. Load Life: 10000 Hours,0.025Ω	SL687M050HJJRR CBE687M1HHSLJ25RR	Ø13.0xL25.0mm	CBE687M1HHSLJ25RR	Data Sheet	View Inventory
Capacitance: 470µF, Tol. ±20%, Voltage 50V, Bulk Ripple Current 2060mA Max. Load Life: 10000 Hours,0.038Ω	SL477M050HGHRR CBE477M1HHSLG20RR	Ø10.0xL20.0mm	CBE477M1HHSLG20RR	Data Sheet	View Inventory
Capacitance: 470µF, Tol. ±20%, Voltage 50V, Bulk Ripple Current 2300mA Max. Load Life: 10000 Hours,0.032Ω	SL477M050HJHRR CBE477M1HHSLJ20RR	Ø13.0xL20.0mm	CBE477M1HHSLJ20RR	Data Sheet	View Inventory
Capacitance: 390µF, Tol. ±20%, Voltage 50V, Bulk Ripple Current 2420mA Max. Load Life: 10000 Hours,0.032Ω	SL397M050HGJRR CBE397M1HHSLG25RR	Ø10.0xL25.0mm	CBE397M1HHSLG25RR	Data Sheet	View Inventory
Capacitance: 330µF, Tol. ±20%, Voltage 50V, Bulk Ripple Current 2060mA Max. Load Life: 10000 Hours,0.038Ω	SL337M050HGHRR CBE337M1HHSLG20RR	Ø10.0xL20.0mm	CBE337M1HHSLG20RR	Data Sheet	View Inventory
Capacitance: 220µF, Tol. ±20%, Voltage 50V, Bulk Ripple Current 1650mA Max. Load Life: 10000 Hours,0.053Ω	SL227M050HGGRR CBE227M1HHSLG16RR	Ø10.0xL16.0mm	CBE227M1HHSLG16RR	Data Sheet	View Inventory
Capacitance: 180µF, Tol. ±20%, Voltage 50V, Bulk Ripple Current 1580mA Max. Load Life: 10000 Hours,0.058Ω	SL187M050HFHRR CBE187M1HHSLF20RR	Ø8.00xL20.0mm	CBE187M1HHSLF20RR	Data Sheet	View Inventory
Capacitance: 150µF, Tol. ±20%, Voltage 50V, Bulk Ripple Current 1280mA Max. Load Life: 9000 Hours,0.073Ω	SL157M050HGDRR CBE157M1HHSLG1BRR	Ø10.0xL12.5mm	CBE157M1HHSLG1BRR	Data Sheet	View Inventory
Capacitance: 120µF, Tol. ±20%, Voltage 50V, Bulk Ripple Current 1230mA Max. Load Life: 10000 Hours,0.082Ω	SL127M050HFGRR CBE127M1HHSLF16RR	Ø8.00xL16.0mm	CBE127M1HHSLF16RR	Data Sheet	View Inventory
Capacitance: 100µF, Tol. ±20%, Voltage 50V, Bulk Ripple Current 950mA Max. Load Life: 9000 Hours,0.12Ω	SL107M050HFCRR CBE107M1HHSLF12RR	Ø8.00xL12.0mm	CBE107M1HHSLF12RR	Data Sheet	View Inventory
Capacitance: 56µF, Tol. ±20%, Voltage 50V, Bulk Ripple Current 500mA Max. Load Life: 7000 Hours,0.22Ω	SL566M050HECRR CBE566M1HHSLE12RR	Ø6.30xL12.0mm	CBE566M1HHSLE12RR	Data Sheet	View Inventory
Capacitance: 1800µF, Tol. ±20%, Voltage 35V, Bulk Ripple Current 3810mA Max. Load Life: 10000 Hours,0.017Ω	SL188M035HKJRR CBE188M1VHSLK25RR	Ø16.0xL25.0mm	CBE188M1VHSLK25RR	Data Sheet	View Inventory
Capacitance: 1500µF, Tol. ±20%, Voltage 35V, Bulk Ripple Current 3330mA Max. Load Life: 10000 Hours,0.021Ω	SL158M035HKHRR CBE158M1VHSLK20RR	Ø16.0xL20.0mm	CBE158M1VHSLK20RR	Data Sheet	View Inventory
Capacitance: 1500µF, Tol. ±20%, Voltage 35V, Bulk Ripple Current 3660mA Max. Load Life: 10000 Hours,0.018Ω	SL158M035HJKRR CBE158M1VHSLJ30RR	Ø13.0xL30.0mm	CBE158M1VHSLJ30RR	Data Sheet	View Inventory
Capacitance: 1200µF, Tol. ±20%, Voltage 35V, Bulk Ripple Current 3200mA Max. Load Life: 10000 Hours,0.019Ω	SL128M035HJJRR CBE128M1VHSLJ25RR	Ø13.0xL25.0mm	CBE128M1VHSLJ25RR	Data Sheet	View Inventory
Capacitance: 1000µF, Tol. ±20%, Voltage 35V, Bulk Ripple Current 2500mA Max. Load Life: 10000 Hours,0.027Ω	SL108M035HGJRR CBE108M1VHSLG25RR	Ø10.0xL25.0mm	CBE108M1VHSLG25RR	Data Sheet	View Inventory
Capacitance: 820µF, Tol. ±20%, Voltage 35V, Bulk Ripple Current 2600mA Max. Load Life: 10000 Hours,0.025Ω	SL827M035HJHRR CBE827M1VHSLJ20RR	Ø13.0xL20.0mm	CBE827M1VHSLJ20RR	Data Sheet	View Inventory
Capacitance: 680µF, Tol. ±20%, Voltage 35V, Bulk Ripple Current 2900mA Max. Load Life: 10000 Hours,0.024Ω	SL687M035HGJRR CBE687M1VHSLG25RR	Ø10.0xL25.0mm	CBE687M1VHSLG25RR	Data Sheet	View Inventory
Capacitance: 560µF, Tol. ±20%, Voltage 35V, Bulk Ripple Current 2500mA Max. Load Life: 10000 Hours,0.028Ω	SL567M035HGHRR CBE567M1VHSLG20RR	Ø10.0xL20.0mm	CBE567M1VHSLG20RR	Data Sheet	View Inventory
Capacitance: 390µF, Tol. ±20%, Voltage 35V, Bulk Ripple Current 2000mA Max. Load Life: 10000 Hours,0.038Ω	SL397M035HGGRR CBE397M1VHSLG16RR	Ø10.0xL16.0mm	CBE397M1VHSLG16RR	Data Sheet	View Inventory
Capacitance: 330µF, Tol. ±20%, Voltage 35V, Bulk Ripple Current 1960mA Max. Load Life: 10000 Hours,0.041Ω	SL337M035HFHRR CBE337M1VHSLF20RR	Ø8.00xL20.0mm	CBE337M1VHSLF20RR	Data Sheet	View Inventory
Capacitance: 270µF, Tol. ±20%, Voltage 35V, Bulk Ripple Current 1700mA Max. Load Life: 9000 Hours,0.053Ω	SL277M035HGDRR CBE277M1VHSLG1BRR	Ø10.0xL12.5mm	CBE277M1VHSLG1BRR	Data Sheet	View Inventory
Capacitance: 220µF, Tol. ±20%, Voltage 35V, Bulk Ripple Current 1600mA Max. Load Life: 10000 Hours,0.059Ω	SL227M035HFGRR CBE227M1VHSLF16RR	Ø8.00xL16.0mm	CBE227M1VHSLF16RR	Data Sheet	View Inventory
Capacitance: 180µF, Tol. ±20%, Voltage 35V, Bulk Ripple Current 1200mA Max. Load Life: 9000 Hours,0.075Ω	SL187M035HFCRR CBE187M1VHSLF12RR	Ø8.00xL12.0mm	CBE187M1VHSLF12RR	Data Sheet	View Inventory
Capacitance: 100µF, Tol. ±20%, Voltage 35V, Bulk Ripple Current 700mA Max. Load Life: 7000 Hours,0.17Ω	SL107M035HECRR CBE107M1VHSLE12RR	Ø6.30xL12.0mm	CBE107M1VHSLE12RR	Data Sheet	View Inventory
Capacitance: 10000µF, Tol. ±20%, Voltage 25V, Bulk Ripple Current 4220mA Max. Load Life: 10000 Hours,0.014Ω	SL109M025HLNRR CBE109M1EHSLL3ERR	Ø18.0xL35.5mm	CBE109M1EHSLL3ERR	Data Sheet	View Inventory
Capacitance: 3300µF, Tol. ±20%, Voltage 25V, Bulk Ripple Current 3810mA Max. Load Life: 10000 Hours,0.017Ω	SL338M025HKJRR CBE338M1EHSLK25RR	Ø16.0xL25.0mm	CBE338M1EHSLK25RR	Data Sheet	View Inventory
Capacitance: 2200µF, Tol. ±20%, Voltage 25V, Bulk Ripple Current 3660mA Max. Load Life: 10000 Hours,0.018Ω	SL228M025HJKRR CBE228M1EHSLJ30RR	Ø13.0xL30.0mm	CBE228M1EHSLJ30RR	Data Sheet	View Inventory
Capacitance: 2200µF, Tol. ±20%, Voltage 25V, Bulk Ripple Current 3330mA Max. Load Life: 10000 Hours,0.021Ω	SL228M025HKHRR CBE228M1EHSLK20RR	Ø16.0xL20.0mm	CBE228M1EHSLK20RR	Data Sheet	View Inventory
Capacitance: 1800µF, Tol. ±20%, Voltage 25V, Bulk Ripple Current 3200mA Max. Load Life: 10000 Hours,0.019Ω	SL188M025HJJRR CBE188M1EHSLJ25RR	Ø13.0xL25.0mm	CBE188M1EHSLJ25RR	Data Sheet	View Inventory
Capacitance: 1500µF, Tol. ±20%, Voltage 25V, Bulk Ripple Current 2600mA Max. Load Life: 10000 Hours,0.025Ω	SL158M025HJHRR CBE158M1EHSLJ20RR	Ø13.0xL20.0mm	CBE158M1EHSLJ20RR	Data Sheet	View Inventory
Capacitance: 1200µF, Tol. ±20%, Voltage 25V, Bulk Ripple Current 2900mA Max. Load Life: 10000 Hours,0.024Ω	SL128M025HGJRR CBE128M1EHSLG25RR	Ø10.0xL25.0mm	CBE128M1EHSLG25RR	Data Sheet	View Inventory
Capacitance: 1000µF, Tol. ±20%, Voltage 25V, Bulk Ripple Current 2500mA Max. Load Life: 10000 Hours,0.028Ω	SL108M025HGHRR CBE108M1EHSLG20RR	Ø10.0xL20.0mm	CBE108M1EHSLG20RR	Data Sheet	View Inventory
Capacitance: 680µF, Tol. ±20%, Voltage 25V, Bulk Ripple Current 2000mA Max. Load Life: 10000 Hours,0.038Ω	SL687M025HGGRR CBE687M1EHSLG16RR	Ø10.0xL16.0mm	CBE687M1EHSLG16RR	Data Sheet	View Inventory
Capacitance: 560µF, Tol. ±20%, Voltage 25V, Bulk Ripple Current 1960mA Max. Load Life: 10000 Hours,0.041Ω	SL567M025HFHRR CBE567M1EHSLF20RR	Ø8.00xL20.0mm	CBE567M1EHSLF20RR	Data Sheet	View Inventory
Capacitance: 470µF, Tol. ±20%, Voltage 25V, Bulk Ripple Current 1700mA Max. Load Life: 9000 Hours,0.053Ω	SL477M025HGDRR CBE477M1EHSLG1BRR	Ø10.0xL12.5mm	CBE477M1EHSLG1BRR	Data Sheet	View Inventory
Capacitance: 390µF, Tol. ±20%, Voltage 25V, Bulk Ripple Current 1600mA Max. Load Life: 10000 Hours,0.059Ω	SL397M025HFGRR CBE397M1EHSLF16RR	Ø8.00xL16.0mm	CBE397M1EHSLF16RR	Data Sheet	View Inventory
Capacitance: 330µF, Tol. ±20%, Voltage 25V, Bulk Ripple Current 1200mA Max. Load Life: 9000 Hours,0.075Ω	SL337M025HFCRR CBE337M1EHSLF12RR	Ø8.00xL12.0mm	CBE337M1EHSLF12RR	Data Sheet	View Inventory
Capacitance: 150µF, Tol. ±20%, Voltage 25V, Bulk Ripple Current 700mA Max. Load Life: 7000 Hours,0.17Ω	SL157M025HECRR CBE157M1EHSLE12RR	Ø6.30xL12.0mm	CBE157M1EHSLE12RR	Data Sheet	View Inventory
Capacitance: 4700µF, Tol. ±20%, Voltage 16V, Bulk Ripple Current 3810mA Max. Load Life: 10000 Hours,0.017Ω	SL478M016HKJRR CBE478M1CHSLK25RR	Ø16.0xL25.0mm	CBE478M1CHSLK25RR	Data Sheet	View Inventory
Capacitance: 3300µF, Tol. ±20%, Voltage 16V, Bulk Ripple Current 3330mA Max. Load Life: 10000 Hours,0.021Ω	SL338M016HKHRR CBE338M1CHSLK20RR	Ø16.0xL20.0mm	CBE338M1CHSLK20RR	Data Sheet	View Inventory
Capacitance: 3300µF, Tol. ±20%, Voltage 16V, Bulk Ripple Current 3660mA Max. Load Life: 10000 Hours,0.018Ω	SL338M016HJKRR CBE338M1CHSLJ30RR	Ø13.0xL30.0mm	CBE338M1CHSLJ30RR	Data Sheet	View Inventory
Capacitance: 2700µF, Tol. ±20%, Voltage 16V, Bulk Ripple Current 3200mA Max. Load Life: 10000 Hours,0.019Ω	SL278M016HJJRR CBE278M1CHSLJ25RR	Ø13.0xL25.0mm	CBE278M1CHSLJ25RR	Data Sheet	View Inventory
Capacitance: 2200µF, Tol. ±20%, Voltage 16V, Bulk Ripple Current 2600mA Max. Load Life: 10000 Hours,0.025Ω	SL228M016HJHRR CBE228M1CHSLJ20RR	Ø13.0xL20.0mm	CBE228M1CHSLJ20RR	Data Sheet	View Inventory
Capacitance: 1800µF, Tol. ±20%, Voltage 16V, Bulk Ripple Current 2900mA Max. Load Life: 10000 Hours,0.024Ω	SL188M016HGJRR CBE188M1CHSLG25RR	Ø10.0xL25.0mm	CBE188M1CHSLG25RR	Data Sheet	View Inventory
Capacitance: 1500µF, Tol. ±20%, Voltage 16V, Bulk Ripple Current 2500mA Max. Load Life: 10000 Hours,0.028Ω	SL158M016HGHRR CBE158M1CHSLG20RR	Ø10.0xL20.0mm	CBE158M1CHSLG20RR	Data Sheet	View Inventory
Capacitance: 1000µF, Tol. ±20%, Voltage 16V, Bulk Ripple Current 2000mA Max. Load Life: 10000 Hours,0.038Ω	SL108M016HGGRR CBE108M1CHSLG16RR	Ø10.0xL16.0mm	CBE108M1CHSLG16RR	Data Sheet	View Inventory
Capacitance: 820µF, Tol. ±20%, Voltage 16V, Bulk Ripple Current 1960mA Max. Load Life: 10000 Hours,0.041Ω	SL827M016HFHRR CBE827M1CHSLF20RR	Ø8.00xL20.0mm	CBE827M1CHSLF20RR	Data Sheet	View Inventory
Capacitance: 680µF, Tol. ±20%, Voltage 16V, Bulk Ripple Current 1700mA Max. Load Life: 9000 Hours,0.053Ω	SL687M016HGDRR CBE687M1CHSLG1BRR	Ø10.0xL12.5mm	CBE687M1CHSLG1BRR	Data Sheet	View Inventory
Capacitance: 560µF, Tol. ±20%, Voltage 16V, Bulk Ripple Current 1600mA Max. Load Life: 10000 Hours,0.059Ω	SL567M016HFGRR CBE567M1CHSLF16RR	Ø8.00xL16.0mm	CBE567M1CHSLF16RR	Data Sheet	View Inventory
Capacitance: 470µF, Tol. ±20%, Voltage 16V, Bulk Ripple Current 1200mA Max. Load Life: 9000 Hours,0.075Ω	SL477M016HFCRR CBE477M1CHSLF12RR	Ø8.00xL12.0mm	CBE477M1CHSLF12RR	Data Sheet	View Inventory
Capacitance: 270µF, Tol. ±20%, Voltage 16V, Bulk Ripple Current 700mA Max. Load Life: 7000 Hours,0.17Ω	SL277M016HEBRR CBE277M1CHSLE11RR	Ø6.30xL11.0mm	CBE277M1CHSLE11RR	Data Sheet	View Inventory
Capacitance: 5600µF, Tol. ±20%, Voltage 10V, Bulk Ripple Current 3810mA Max. Load Life: 10000 Hours,0.017Ω	SL568M010HKJRR CBE568M1AHSLK25RR	Ø16.0xL25.0mm	CBE568M1AHSLK25RR	Data Sheet	View Inventory
Capacitance: 5600µF, Tol. ±20%, Voltage 10V, Bulk Ripple Current 4120mA Max. Load Life: 10000 Hours,0.016Ω	SL568M010HJMRR CBE568M1AHSLJ35RR	Ø13.0xL35.0mm	CBE568M1AHSLJ35RR	Data Sheet	View Inventory
Capacitance: 4700µF, Tol. ±20%, Voltage 10V, Bulk Ripple Current 3330mA Max. Load Life: 10000 Hours,0.021Ω	SL478M010HKHRR CBE478M1AHSLK20RR	Ø16.0xL20.0mm	CBE478M1AHSLK20RR	Data Sheet	View Inventory
Capacitance: 4700µF, Tol. ±20%, Voltage 10V, Bulk Ripple Current 3660mA Max. Load Life: 10000 Hours,0.018Ω	SL478M010HJKRR CBE478M1AHSLJ30RR	Ø13.0xL30.0mm	CBE478M1AHSLJ30RR	Data Sheet	View Inventory
Capacitance: 3300µF, Tol. ±20%, Voltage 10V, Bulk Ripple Current 3200mA Max. Load Life: 10000 Hours,0.019Ω	SL338M010HJJRR CBE338M1AHSLJ25RR	Ø13.0xL25.0mm	CBE338M1AHSLJ25RR	Data Sheet	View Inventory
Capacitance: 2700µF, Tol. ±20%, Voltage 10V, Bulk Ripple Current 2600mA Max. Load Life: 10000 Hours,0.025Ω	SL278M010HJHRR CBE278M1AHSLJ20RR	Ø13.0xL20.0mm	CBE278M1AHSLJ20RR	Data Sheet	View Inventory
Capacitance: 2200µF, Tol. ±20%, Voltage 10V, Bulk Ripple Current 2900mA Max. Load Life: 10000 Hours,0.024Ω	SL228M010HGJRR CBE228M1AHSLG25RR	Ø10.0xL25.0mm	CBE228M1AHSLG25RR	Data Sheet	View Inventory
Capacitance: 1800µF, Tol. ±20%, Voltage 10V, Bulk Ripple Current 2500mA Max. Load Life: 10000 Hours,0.028Ω	SL188M010HGHRR CBE188M1AHSLG20RR	Ø10.0xL20.0mm	CBE188M1AHSLG20RR	Data Sheet	View Inventory
Capacitance: 1200µF, Tol. ±20%, Voltage 10V, Bulk Ripple Current 2000mA Max. Load Life: 10000 Hours,0.038Ω	SL128M010HGGRR CBE128M1AHSLG16RR	Ø10.0xL16.0mm	CBE128M1AHSLG16RR	Data Sheet	View Inventory
Capacitance: 1000µF, Tol. ±20%, Voltage 10V, Bulk Ripple Current 1960mA Max. Load Life: 10000 Hours,0.041Ω	SL108M010HFHRR CBE108M1AHSLF20RR	Ø8.00xL20.0mm	CBE108M1AHSLF20RR	Data Sheet	View Inventory
Capacitance: 820µF, Tol. ±20%, Voltage 10V, Bulk Ripple Current 1700mA Max. Load Life: 9000 Hours,0.053Ω	SL827M010HGDRR CBE827M1AHSLG1BRR	Ø10.0xL12.5mm	CBE827M1AHSLG1BRR	Data Sheet	View Inventory
Capacitance: 680µF, Tol. ±20%, Voltage 10V, Bulk Ripple Current 1600mA Max. Load Life: 10000 Hours,0.059Ω	SL687M010HFGRR CBE687M1AHSLF16RR	Ø8.00xL16.0mm	CBE687M1AHSLF16RR	Data Sheet	View Inventory
Capacitance: 560µF, Tol. ±20%, Voltage 10V, Bulk Ripple Current 1200mA Max. Load Life: 9000 Hours,0.075Ω	SL567M010HFCRR CBE567M1AHSLF12RR	Ø8.00xL12.0mm	CBE567M1AHSLF12RR	Data Sheet	View Inventory
Capacitance: 330µF, Tol. ±20%, Voltage 10V, Bulk Ripple Current 700mA Max. Load Life: 7000 Hours,0.17Ω	SL337M010HEBRR CBE337M1AHSLE11RR	Ø6.30xL11.0mm	CBE337M1AHSLE11RR	Data Sheet	View Inventory
Capacitance: 8200µF, Tol. ±20%, Voltage 6.3V, Bulk Ripple Current 3630mA Max. Load Life: 10000 Hours,0.017Ω	SL828M6V3HKJRR CBE828M0JHSLK25RR	Ø16.0xL25.0mm	CBE828M0JHSLK25RR	Data Sheet	View Inventory
Capacitance: 6800µF, Tol. ±20%, Voltage 6.3V, Bulk Ripple Current 3250mA Max. Load Life: 10000 Hours,0.021Ω	SL688M6V3HKHRR CBE688M0JHSLK20RR	Ø16.0xL20.0mm	CBE688M0JHSLK20RR	Data Sheet	View Inventory
Capacitance: 5600µF, Tol. ±20%, Voltage 6.3V, Bulk Ripple Current 3450mA Max. Load Life: 10000 Hours,0.018Ω	SL568M6V3HJKRR CBE568M0JHSLJ30RR	Ø13.0xL30.0mm	CBE568M0JHSLJ30RR	Data Sheet	View Inventory
Capacitance: 4700µF, Tol. ±20%, Voltage 6.3V, Bulk Ripple Current 2900mA Max. Load Life: 10000 Hours,0.019Ω	SL478M6V3HJJRR CBE478M0JHSLJ25RR	Ø13.0xL25.0mm	CBE478M0JHSLJ25RR	Data Sheet	View Inventory
Capacitance: 3900µF, Tol. ±20%, Voltage 6.3V, Bulk Ripple Current 2480mA Max. Load Life: 10000 Hours,0.025Ω	SL398M6V3HJHRR CBE398M0JHSLJ20RR	Ø13.0xL20.0mm	CBE398M0JHSLJ20RR	Data Sheet	View Inventory
Capacitance: 3300µF, Tol. ±20%, Voltage 6.3V, Bulk Ripple Current 2250mA Max. Load Life: 10000 Hours,0.024Ω	SL338M6V3HGJRR CBE338M0JHSLG25RR	Ø10.0xL25.0mm	CBE338M0JHSLG25RR	Data Sheet	View Inventory
Capacitance: 2700µF, Tol. ±20%, Voltage 6.3V, Bulk Ripple Current 1960mA Max. Load Life: 10000 Hours,0.028Ω	SL278M6V3HGHRR CBE278M0JHSLG20RR	Ø10.0xL20.0mm	CBE278M0JHSLG20RR	Data Sheet	View Inventory
Capacitance: 1800µF, Tol. ±20%, Voltage 6.3V, Bulk Ripple Current 1760mA Max. Load Life: 10000 Hours,0.038Ω	SL188M6V3HGGRR CBE188M0JHSLG16RR	Ø10.0xL16.0mm	CBE188M0JHSLG16RR	Data Sheet	View Inventory
Capacitance: 1500µF, Tol. ±20%, Voltage 6.3V, Bulk Ripple Current 1500mA Max. Load Life: 9000 Hours,0.041Ω	SL158M6V3HFHRR CBE158M0JHSLF20RR	Ø8.00xL20.0mm	CBE158M0JHSLF20RR	Data Sheet	View Inventory
Capacitance: 1200µF, Tol. ±20%, Voltage 6.3V, Bulk Ripple Current 1330mA Max. Load Life: 9000 Hours,0.053Ω	SL128M6V3HGDRR CBE128M0JHSLG1BRR	Ø10.0xL12.5mm	CBE128M0JHSLG1BRR	Data Sheet	View Inventory
Capacitance: 1000µF, Tol. ±20%, Voltage 6.3V, Bulk Ripple Current 1250mA Max. Load Life: 9000 Hours,0.059Ω	SL108M6V3HFGRR CBE108M0JHSLF16RR	Ø8.0xL16.0mm	CBE108M0JHSLF16RR	Data Sheet	View Inventory
Capacitance: 820µF, Tol. ±20%, Voltage 6.3V, Bulk Ripple Current 945mA Max. Load Life: 8000 Hours,0.075Ω	SL827M6V3HFCRR CBE827M0JHSLF12RR	Ø8.00xL12.0mm	CBE827M0JHSLF12RR	Data Sheet	View Inventory
Capacitance: 470µF, Tol. ±20%, Voltage 6.3V, Bulk Ripple Current 540mA Max. Load Life: 6000 Hours,0.17Ω	SL477M6V3HEBRR CBE477M0JHSLE11RR	Ø6.30xL11.0mm	CBE477M0JHSLE11RR	Data Sheet	View Inventory
Capacitance: 100µF, Tol. ±20%, Voltage 35V, Bulk Ripple Current 1300mA Max. Load Life: 10000 Hours,0.065Ω	SL107M035HGDT5 CBE107M1VHSLG1BT5A	Ø10.0xL12.5mm	CBE107M1VHSLG1BT5A	Data Sheet	View Inventory

PRODUCTS

Aluminum Elec. Capacitor

Dip 1C/1T Dip 3D/3H Dip 7T/8T Dip 93/94 Dip CZ Dip DP Dip EP/EZ Dip FP Dip GT Dip JA Dip RD Dip RF Dip RH Dip RT Dip RW Dip SL SMD BW Polymer SMD BZ Polymer SMD FZ SMD UE SMD UH/UL SMD UT SMD UZ SMD VM SMD ZH/ZL/ZS/ZT/ZU

Automotive Grade Crystal

XG3225 XS3225 XS2016 XG5032

Cement Resistor

SQM Series SQP Series SQZ Series

Ceramic Resonator

CD(CRTWS) CG(CRAV) CH(CRTE) CJ(CRAW) CK(CRTC) CL(CRTS) CM(CRTV) CN(CRTW) CP(CRTP) CQ(CRAP) CR(CRTR) CS(CRAS) CU(CRAR)

Connectors

Contacts Rectangular Connectors Circular Connectors PCB Connectors Smart Grid Connectors New EV Connectors IO Link Energy Storage Connectors Cable Glands Custom Products Custom Wire Harness Underwater Connectors High Mating Cycle Connectors Tools

Diode/Transistor/MOSFET

Bridge Rectifier Fast Recovery Diode Switching Diode General Purpose Diode High Efficiency Diode Schottky Diode Transistor Super Fast Diode TVS Diode Zener Diode ESD Diode MOSFET TVs SM8S series AEC-Q101 TVs P6SMB Series TVs TP6SMB Series AEC-Q101

Discriminator & Filter

Discriminators DC Series 450KHz/455KHz & DV Series 10.7MHz Filter FF/FG/FK Series 10.7MHz Filter FL/FM Series 450KHz/455KHz Filter FB Series 450KHz/455KHz Dip Type Filter LTM Series 450KHz/455KHz Dip Type

Inductor/Coils/Choke

Power Inductor Multilayer Chip Power Inductor Chip Common Mode Inductor

Metallized Film Capacitor

Dip MKP series

Light-Emitting Diode (LED)

Auto. SMD LED 3528 PLCC-2 Auto. SMD LED 3528 PLCC-4 Auto. SMD LED 3433 PLCC-6 Auto. SMD LED 4040 Side View LED Lamp Dip Type SMD 0603/0805/1206/1615

Miniature Fuses

SCF520 SCF632 SCF632A SC625 SCF625 SCT520 SGT520 SGF520 SCF632H SCF1032 SCT1032 SCF6125 SCT6125 SCF61011 SPF478 SPT478

MLCCs

Low Voltage 6.3V ~100V Medium Voltage 200V~ 630V High Voltage 1000V ~ 4000V Automotive Application (AEC-Q200) MT series High Q & Low ESR RF Series Soft Termination SH Series Industrial Grade B Series Commercial Grade C Series Automotive Powertrain & Safety Grade E Series High-Q & High-Power Grade P Series High-Q & High-Frequency Grade U Series Automotive A Series CCTC MLCCs

Oscillator

RA(CO14) RB(CO8) RC(COM75) RD(COM53) RE(COM32) RF(COM22) RJ(COK21)/RK(COK22)/RL(COK32)/RM(COK53)/RN(COK75) RV(COM21) RY(COM11)

Quartz Crystal

XB(CM75) XC/XD(CM63/CM53) XF(CM32) XG(CA) XI(CM22) XS/XJ(CS/CSS) XM/XK/XN(CSM2/CSSM2/CSSM5) XP(CMG632) XR(CMG532) XV(CM21) XY(CM11) XZ(CM12) YA/YB/YD(CCA/CCB/CCD) YG(CCMD) YL/YR/YS/YT(CCMJ/CCMM/CCMS/CCMN) YN (CCMA) YP (CCMC) YQ(CCME) YU/YV(CCMU/CCMV) XH (HC-49SX)

SAW Filter/SAW Resonator

SAW Filter SAF/SHF/SXF SAW Filter SBF SAW Filter SDF SAW Resonator SAR SAW Resonator SBR SAW Resonator SCR/SER/SGR SAW Resonator SDR SAW Resonator SIR

SiC Schottky/MOSFET/Wafer

SiC Schottky Diode SiC MOSFET Silicon Wafer

Super Capacitor (EDLC)

EM Series

Tantalum Capacitor

CA42 A Dip Type CA45 A CA45 B CA45 C CA45 D CA45 E CA45L A/B/C/D/E CA45 P SMD Conductive Polymer CA55 A/B/C SMD Conductive Polymer CA55 D/E/F/H

Thermistor Crystal

TSX2520 TSX2016 TSX1612

Thick/Thin Resistor

Wire Wound SMW series Thick Film CR series Thick Film CL series Thick Film CP series Thick Film RCR series Thin Film ARU/UR series Thick Film ATP series

SL107M035HGDT5
CBE107M1VHSLG1BT5A


Description and Main Parameters

Capacitance: 100µF, Tol. ±20%, Voltage 35V, Bulk
Ripple Current 1300mA Max. Load Life: 10000 Hours,0.065Ω

Dimension

Ø10.0xL12.5mm

Original Part Number

CBE107M1VHSLG1BT5A

Documents

Data Sheet View Inventory

SL827M100HLORR
CBE827M2AHSLL40RR


Description and Main Parameters

Capacitance: 820µF, Tol. ±20%, Voltage 100V, Bulk
Ripple Current 3860mA Max. Load Life: 10000 Hours,0.026Ω

Dimension

Ø18.0xL40.0mm

Original Part Number

CBE827M2AHSLL40RR

Documents

Data Sheet View Inventory

SL687M100HLNRR
CBE687M2AHSLL3ERR


Description and Main Parameters

Capacitance: 680µF, Tol. ±20%, Voltage 100V, Bulk
Ripple Current 3510mA Max. Load Life: 10000 Hours,0.027Ω

Dimension

Ø18.0xL35.5mm

Original Part Number

CBE687M2AHSLL3ERR

Documents

Data Sheet View Inventory

SL687M100HKORR
CBE687M2AHSLK40RR


Description and Main Parameters

Capacitance: 680µF, Tol. ±20%, Voltage 100V, Bulk
Ripple Current 3510mA Max. Load Life: 10000 Hours,0.027Ω

Dimension

Ø16.0xL40.0mm

Original Part Number

CBE687M2AHSLK40RR

Documents

Data Sheet View Inventory

SL567M100HLLRR
CBE567M2AHSLL3ARR


Description and Main Parameters

Capacitance: 560µF, Tol. ±20%, Voltage 100V, Bulk
Ripple Current 2860mA Max. Load Life: 10000 Hours,0.030Ω

Dimension

Ø18.0xL31.5mm

Original Part Number

CBE567M2AHSLL3ARR

Documents

Data Sheet View Inventory

SL567M100HKNRR
CBE567M2AHSLK3ERR


Description and Main Parameters

Capacitance: 560µF, Tol. ±20%, Voltage 100V, Bulk
Ripple Current 2860mA Max. Load Life: 10000 Hours,0.029Ω

Dimension

Ø16.0xL35.5mm

Original Part Number

CBE567M2AHSLK3ERR

Documents

Data Sheet View Inventory

SL477M100HLJRR
CBE477M2AHSLL25RR


Description and Main Parameters

Capacitance: 470µF, Tol. ±20%, Voltage 100V, Bulk
Ripple Current 2500mA Max. Load Life: 10000 Hours,0.036Ω

Dimension

Ø18.0xL25.0mm

Original Part Number

CBE477M2AHSLL25RR

Documents

Data Sheet View Inventory

SL477M100HKLRR
CBE477M2AHSLK3ARR


Description and Main Parameters

Capacitance: 470µF, Tol. ±20%, Voltage 100V, Bulk
Ripple Current 2640mA Max. Load Life: 10000 Hours,0.032Ω

Dimension

Ø16.0xL31.5mm

Original Part Number

CBE477M2AHSLK3ARR

Documents

Data Sheet View Inventory

SL397M100HLHRR
CBE397M2AHSLL20RR


Description and Main Parameters

Capacitance: 390µF, Tol. ±20%, Voltage 100V, Bulk
Ripple Current 2270mA Max. Load Life: 10000 Hours,0.045Ω

Dimension

Ø18.0xL20.0mm

Original Part Number

CBE397M2AHSLL20RR

Documents

Data Sheet View Inventory

SL397M100HKJRR
CBE397M2AHSLK25RR


Description and Main Parameters

Capacitance: 390µF, Tol. ±20%, Voltage 100V, Bulk
Ripple Current 2430mA Max. Load Life: 10000 Hours,0.038Ω

Dimension

Ø16.0xL25.0mm

Original Part Number

CBE397M2AHSLK25RR

Documents

Data Sheet View Inventory

Click to load more

PRODUCTS

Aluminum Elec. Capacitor

Automotive Grade Crystal

Cement Resistor

Ceramic Resonator

Connectors

Diode/Transistor/MOSFET

Discriminator & Filter

Inductor/Coils/Choke

Metallized Film Capacitor

Light-Emitting Diode (LED)

Miniature Fuses

MLCCs

Oscillator

Quartz Crystal

SAW Filter/SAW Resonator

SiC Schottky/MOSFET/Wafer

Super Capacitor (EDLC)

Tantalum Capacitor

Thermistor Crystal

Thick/Thin Resistor

Download Center

Contact Us
