Super Capacitor (EDLC)
PROUDCTS（ A ~ Z )
Aluminum Elec. Capacitor Diode/Transistor/MOSFET Discriminator & Filter Inductor/Coils/Choke Light-Emitting Diode (LED) ML. Chip Capacitor (MLCC) Metallized Film Capacitor Oscillator Quartz Crystal Relay Resonator Resistor SAW SiC Schottky Diode/MOSFET Super Capacitor (EDLC) Tantalum Capacitor
Super Capacitor (EDLC)

ALL

EM Series

Image Description and Main Parameters Part Series Code Dimension Original Part Number Documents
Capacitance: 0.47F, Tol. -20%~+80%, Voltage 5.5V, RC Type Bulk
ESR AC @1kHz, 20°C: 40 ohm Max. Leakage Current: 2µA @72 hours		 EM474Z05H11CCA ØD13.4*H13.5mm CEE474Z05HEM11CRC Data Sheet View Inventory
Capacitance: 0.47F, Tol. -20%~+80%, Voltage 5.5V, RH Type Bulk
ESR AC @1kHz, 20°C: 40 ohm Max. Leakage Current: 2µA @72 hours		 EM474Z05H6N2HA ØD11.7*H6.2mm CEE474Z05HEM6N2RH Data Sheet View Inventory
Capacitance: 0.33F, Tol. -20%~+80%, Voltage 5.5V, RC Type Bulk
ESR AC @1kHz, 20°C: 40 ohm Max. Leakage Current: 1µA @72 hours		 EM334Z05H11CCA ØD13.4*H13.5mm CEE334Z05HEM11CRC Data Sheet View Inventory
Capacitance: 0.33F, Tol. -20%~+80%, Voltage 5.5V, RV Type Bulk
ESR AC @1kHz, 20°C: 40 ohm Max. Leakage Current: 1µA @72 hours		 EM334Z05H6S7VA ØD11.7*H16.7mm CEE334Z05HEM6S7RV Data Sheet View Inventory
Capacitance: 0.33F, Tol. -20%~+80%, Voltage 5.5V, RH Type Bulk
ESR AC @1kHz, 20°C: 40 ohm Max. Leakage Current: 1µA @72 hours		 EM334Z05H6N2HA ØD11.7*H6.2mm CEE334Z05HEM6N2RH Data Sheet View Inventory
Capacitance: 0.22F, Tol. -20%~+80%, Voltage 5.5V, RC Type Bulk
ESR AC @1kHz, 20°C: 40 ohm Max. Leakage Current: 1µA @72 hours		 EM224Z05H11CCA ØD13.4*H13.5mm CEE224Z05HEM11CRC Data Sheet View Inventory
Capacitance: 0.22F, Tol. -20%~+80%, Voltage 5.5V, RV Type Bulk
ESR AC @1kHz, 20°C: 40 ohm Max. Leakage Current: 1µA @72 hours		 EM224Z05H6S7VA ØD11.7*H16.7mm CEE224Z05HEM6S7RV Data Sheet View Inventory
Capacitance: 0.22F, Tol. -20%~+80%, Voltage 5.5V, RH Type Bulk
ESR AC @1kHz, 20°C: 40 ohm Max. Leakage Current: 1µA @72 hours		 EM224Z05H6N2HA ØD11.7*H6.2mm CEE224Z05HEM6N2RH Data Sheet View Inventory
Capacitance: 1.5F, Tol. -20%~+80%, Voltage 5.5V, RH Type Bulk
ESR AC @1kHz, 20°C: 15 ohm Max. Leakage Current: 3µA @72 hours		 EM155Z05HZT3HA ØD19.1*H10.3mm CEE155Z05HEMZT3RH Data Sheet View Inventory
Capacitance: 1.5F, Tol. -20%~+80%, Voltage 5.5V, RV Type Bulk
ESR AC @1kHz, 20°C: 15 ohm Max. Leakage Current: 3µA @72 hours		 EM155Z05HZR2VA ØD19.1*H24.2mm CEE155Z05HEMZR2RV Data Sheet View Inventory
Capacitance: 1.5F, Tol. -20%~+80%, Voltage 5.5V, RC Type Bulk
ESR AC @1kHz, 20°C: 15 ohm Max. Leakage Current: 3µA @72 hours		 EM155Z05HTF2CA ØD20.9*H14.2mm CEE155Z05HEMTF2RC Data Sheet View Inventory
Capacitance: 1.0F, Tol. -20%~+80%, Voltage 5.5V, RH Type Bulk
ESR AC @1kHz, 20°C: 15 ohm Max. Leakage Current: 2µA @72 hours		 EM105Z05HZT3HA ØD19.1*H10.3mm CEE105Z05HEMZT3RH Data Sheet View Inventory
Capacitance: 1.0F, Tol. -20%~+80%, Voltage 5.5V, RV Type Bulk
ESR AC @1kHz, 20°C: 15 ohm Max. Leakage Currnt: 2µA @72 hours		 EM105Z05HZR2VA ØD19.1*H24.2mm CEE105Z05HEMZR2RV Data Sheet View Inventory
Capacitance: 1.0F, Tol. -20%~+80%, Voltage 5.5V, RC Type Bulk
ESR AC @1kHz, 20°C: 15 ohm Max. Leakage Current: 2µA @72 hours		 EM105Z05HTF2CA ØD20.9*H14.2mm CEE105Z05HEMTF2RC Data Sheet View Inventory
Capacitance: 0.1F, Tol. -20%~+80%, Voltage 5.5V, RV Type Bulk
ESR AC @1kHz, 20°C: 50 ohm Max. Leakage Currnt: 1µA @72 hours		 EM104Z05H6S7VA ØD11.7*H16.7mm CEE104Z05HEM6S7RV Data Sheet View Inventory
Capacitance: 0.1F, Tol. -20%~+80%, Voltage 5.5V, RC Type Bulk
ESR AC @1kHz, 20°C: 50 ohm Max. Leakage Current: 1µA @72 hours		 EM104Z05H11CCA ØD13.4*H13.5mm CEE104Z05HEM11CRC Data Sheet View Inventory
Capacitance: 0.47F, Tol. -20%~+80%, Voltage 5.5V, RV Type Bulk
ESR AC @1kHz, 20°C: 40 ohm Max. Leakage Currnt: 2µA @72 hours		 EM474Z05H6S7VA ØD11.70*H16.7mm CEE474Z05HEM6S7RV Data Sheet View Inventory
Capacitance: 0.1F, Tol. -20%~+80%, Voltage 5.5V, RH Type Bulk
ESR AC @1kHz, 20°C: 50 ohm Max. Leakage Current: 1µA @72 hours		 EM104Z05H6N2HA ØD11.70*H6.2mm CEE104Z05HEM6N2RH Data Sheet View Inventory

PRODUCTS

Aluminum Elec. Capacitor

Dip Type SMD UE Series SMD UH/UL Series SMD UT Series SMD UZ Series SMD ZL/ZS/ZT Series SMD BW series SMD BZ seies SMD FZ series

Diode/Transistor/MOSFET

Bridge Rectifier Fast Recovery Diode Switching Diode General Purpose Diode High Efficiency Diode Schottky Diode Transistor Super Fast Diode TVS Diode Zener Diode ESD Diode MOSFET

Discriminator & Filter

Discriminators 10.7MHz Discriminators 450KHz Discriminators 455KHz Filter 10.7MHz Filter 450KHz/455KHz SMD type Filter 450KHz/455KHz Dip Type

Inductor/Coils/Choke

Power Inductor Multilayer Chip Power Inductor Chip Common Mode Inductor

Light-Emitting Diode (LED)

Auto. SMD LED 3528 PLCC-2 Auto. SMD LED 3528 PLCC-4 Auto. SMD LED 3433 PLCC-6 Auto. SMD LED 4040 Side View LED Lamp Dip Type SMD 0603/0805/1206/1615

ML. Chip Capacitor (MLCC)

0201 0402 0603 0805 1206 1210/1808/1812 MT02/MT03/MT05/MT06 RF01/RF02/RF03 SH02/SH03/SH05/SH06/SH10/SH08/SH12/ST05

Metallized Film Capacitor

Dip MKP series

Oscillator

RA(CO14) RB(CO8) RC(COM75) RD(COM53) RE(COM32) RF(COM22) RJ(COK21)/RK(COK22)/RL(COK32)/RM(COK53)/RN(COK75) RV(COM21) RY(COM11)

Quartz Crystal

XB(CM75) XC/XD(CM63/CM53) XF(CM32) XG(CA) XI(CM22) XS/XJ(CS/CSS) XM/XK/XN(CSM2/CSSM2/CSSM5) XP(CMG632) XR(CMG532) XV(CM21) XY(CM11) XZ(CM12) YA/YB/YD(CCA/CCB/CCD) YG(CCMD) YL/YR/YS(CCMJ/CCMM/CCMS) YN (CCMA) YP (CCMC) YQ(CCME) YU/YV(CCMU/CCMV)

Relay

General Power Relay Automotive Relay Signal Relay

Resonator

CA/CB(CRA/CRB) CD(CRTWS) CG(CRAV) CH(CRTE) CJ(CRAW) CK(CRTC) CL(CRTS) CM(CRTV) CN(CRTW) CP(CRTP) CQ(CRAP) CR(CRTR) CS(CRAS) CT(CRT) CU(CRAR)

Resistor

Wire Wound SMW series Thick Film CR series Thick Film CL series Thick Film CP series Thick Film RCR series Think Film ARU/UR series

SAW

SAW Filter SAF SAW Filter SBF SAW Filter SDF SAW Resonator SAR SAW Resonator SBR SAW Resonator SCR/SER/SGR SAW Resonator SDR SAW Resonator SIR

SiC Schottky Diode/MOSFET

SiC Schottky Diode SiC MOSFET

Super Capacitor (EDLC)

EM Series

Tantalum Capacitor

CA42 A Dip Type CA45 A CA45 B CA45 C CA45 D CA45 E CA45L A/B/C/D/E CA45 P CA55 A/B/C CA55 D/E/F/H
EM104Z05H6N2HA
Description and Main Parameters
Capacitance: 0.1F, Tol. -20%~+80%, Voltage 5.5V, RH Type Bulk
ESR AC @1kHz, 20°C: 50 ohm Max. Leakage Current: 1µA @72 hours
Dimension
ØD11.70*H6.2mm
Original Part Number
CEE104Z05HEM6N2RH
Documents
Data Sheet View Inventory
EM104Z05H11CCA
Description and Main Parameters
Capacitance: 0.1F, Tol. -20%~+80%, Voltage 5.5V, RC Type Bulk
ESR AC @1kHz, 20°C: 50 ohm Max. Leakage Current: 1µA @72 hours
Dimension
ØD13.4*H13.5mm
Original Part Number
CEE104Z05HEM11CRC
Documents
Data Sheet View Inventory
EM474Z05H6S7VA
Description and Main Parameters
Capacitance: 0.47F, Tol. -20%~+80%, Voltage 5.5V, RV Type Bulk
ESR AC @1kHz, 20°C: 40 ohm Max. Leakage Currnt: 2µA @72 hours
Dimension
ØD11.70*H16.7mm
Original Part Number
CEE474Z05HEM6S7RV
Documents
Data Sheet View Inventory
EM474Z05H11CCA
Description and Main Parameters
Capacitance: 0.47F, Tol. -20%~+80%, Voltage 5.5V, RC Type Bulk
ESR AC @1kHz, 20°C: 40 ohm Max. Leakage Current: 2µA @72 hours
Dimension
ØD13.4*H13.5mm
Original Part Number
CEE474Z05HEM11CRC
Documents
Data Sheet View Inventory
EM474Z05H6N2HA
Description and Main Parameters
Capacitance: 0.47F, Tol. -20%~+80%, Voltage 5.5V, RH Type Bulk
ESR AC @1kHz, 20°C: 40 ohm Max. Leakage Current: 2µA @72 hours
Dimension
ØD11.7*H6.2mm
Original Part Number
CEE474Z05HEM6N2RH
Documents
Data Sheet View Inventory
EM334Z05H11CCA
Description and Main Parameters
Capacitance: 0.33F, Tol. -20%~+80%, Voltage 5.5V, RC Type Bulk
ESR AC @1kHz, 20°C: 40 ohm Max. Leakage Current: 1µA @72 hours
Dimension
ØD13.4*H13.5mm
Original Part Number
CEE334Z05HEM11CRC
Documents
Data Sheet View Inventory
EM334Z05H6S7VA
Description and Main Parameters
Capacitance: 0.33F, Tol. -20%~+80%, Voltage 5.5V, RV Type Bulk
ESR AC @1kHz, 20°C: 40 ohm Max. Leakage Current: 1µA @72 hours
Dimension
ØD11.7*H16.7mm
Original Part Number
CEE334Z05HEM6S7RV
Documents
Data Sheet View Inventory
EM334Z05H6N2HA
Description and Main Parameters
Capacitance: 0.33F, Tol. -20%~+80%, Voltage 5.5V, RH Type Bulk
ESR AC @1kHz, 20°C: 40 ohm Max. Leakage Current: 1µA @72 hours
Dimension
ØD11.7*H6.2mm
Original Part Number
CEE334Z05HEM6N2RH
Documents
Data Sheet View Inventory
EM224Z05H11CCA
Description and Main Parameters
Capacitance: 0.22F, Tol. -20%~+80%, Voltage 5.5V, RC Type Bulk
ESR AC @1kHz, 20°C: 40 ohm Max. Leakage Current: 1µA @72 hours
Dimension
ØD13.4*H13.5mm
Original Part Number
CEE224Z05HEM11CRC
Documents
Data Sheet View Inventory
EM224Z05H6S7VA
Description and Main Parameters
Capacitance: 0.22F, Tol. -20%~+80%, Voltage 5.5V, RV Type Bulk
ESR AC @1kHz, 20°C: 40 ohm Max. Leakage Current: 1µA @72 hours
Dimension
ØD11.7*H16.7mm
Original Part Number
CEE224Z05HEM6S7RV
Documents
Data Sheet View Inventory
Click to load more
